CS377: Database Design - Data Organization: Fields, Records, and Keys
Activity Goals
The goals of this activity are:- To define a record, field, and key in a database system
- To explain the importance and challenges of internal consistency
- To represent sparse data compactly with Compressed Sparse Row (CSR) storage and decode it back to its original form
The Activity
Directions
Consider the activity models and answer the questions provided. First reflect on these questions on your own briefly, before discussing and comparing your thoughts with your group. Appoint one member of your group to discuss your findings with the class, and the rest of the group should help that member prepare their response. Answer each question individually from the activity, and compare with your group to prepare for our whole-class discussion. After class, think about the questions in the reflective prompt and respond to those individually in your notebook. Report out on areas of disagreement or items for which you and your group identified alternative approaches. Write down and report out questions you encountered along the way for group discussion.Model 1: Records, Fields, and Keys
Questions
- What records do you see in the data? What fields?
- What should happen if a particular field does not have a value?
- Two records are sometimes linked together; what do you think this means in this application?
- The two records are somewhat different; how, and what should be done about this?
- What field(s) are most likely to be unique throughout the table? These are referred to as a key, but a single serial number is often used instead to guarantee uniqueness.
Model 2: Internal Consistency
Questions
- Which fields should a user be able to update? Which ones should a user not update directly, and why?
Model 3: Compressed Sparse Row (CSR) Storage
| col 0 | col 1 | col 2 | |
|---|---|---|---|
| row 0 | 1 | 0 | 2 |
| row 1 | 0 | 3 | 4 |
| row 2 | 5 | 6 | 7 |
data = [1, 2, 3, 4, 5, 6, 7] # the nonzero values, row by row indices = [0, 2, 1, 2, 0, 1, 2] # the column of each value indptr = [0, 2, 4, 7] # where each row starts in data
Questions
- Using only the three arrays, reconstruct row 1 of the matrix:
indptr[1] = 2andindptr[2] = 4, so row 1's values aredata[2:4]in columnsindices[2:4]. What are they, and does your answer match the table? - How many values does row
icontain, in terms ofindptr? What does it mean whenindptr[i] == indptr[i+1]? - The dense 3×3 matrix stores 9 numbers; CSR stores 7 + 7 + 4 = 18. For this small, mostly-full matrix, CSR is bigger! For what kinds of data does CSR win, and by how much would it win for a 1,000,000 × 1,000,000 matrix with 10 nonzeros per row?
- Run the embedded example, which stores a graph's edges as a CSR adjacency matrix and traverses it with depth-first search. Where in the code are
indptrandindicesused to find a node's neighbors?
Embedded Code Environment
You can try out these code examples in a development environment of your choice! Note that some embedded projects have multiple source files; you can see those by clicking the appropriate file tab to open that file.In the field of databases and data management, it is essential to understand how data is organized to effectively store, retrieve, and manipulate information. One fundamental concept is the organization of data into fields, records, and keys, which forms the foundation of many database systems. In this context, a field represents an individual data item, a record represents a set of related fields, and a key serves as a unique identifier for each record.
Fields
A field is a single piece of information stored in a database. It represents an attribute of an entity or an object. For instance, in a database of employees, fields could include the employee’s name, age, and job title. Each field contains a specific type of data, such as text, number, date, or Boolean.
A field, also known as an attribute, is the smallest unit of data in a database system. It can hold various types of data, such as numbers, text, dates, or even binary values. Fields should be carefully defined to ensure consistency and accuracy in data representation. For instance, when designing a database for a library, fields like book title, author, publication year, and ISBN number can be defined to store relevant information.
In Python, fields can be represented using variables of appropriate data types. For example, consider a field called age to store the age of individuals. We can define and assign a value to this field as follows:
age = 25
Records
Records are collections of related fields that represent a complete unit of information. In the context of a database, a record typically refers to a row in a table. For example, an employee record may include fields such as name, age, job title, department, and salary.
A record is a collection of related fields that together represent a complete set of information. Records allow us to organize data efficiently and facilitate data retrieval and manipulation operations. In the library database example, each book can be represented as a record, consisting of fields such as title, author, publication year, and ISBN number.
In Python, records can be represented using various data structures such as lists, tuples, or dictionaries. For instance, suppose we define a record representing a person’s information as a dictionary:
person = {
"name": "John",
"age": 25,
"gender": "Male"
}
Here, the keys "name", "age", and "gender" represent the fields, and their corresponding values represent the data associated with each field.
Keys
A key is a field or combination of fields used to uniquely identify each record within a database table. Keys are crucial for efficient querying and indexing operations. A primary key is a unique identifier for a record and is often used as a reference for other tables. Alternatively, a composite key is a combination of two or more fields that, when combined, uniquely identify a record. There are various types of keys, such as primary keys, candidate keys, and foreign keys.
In Python, keys can be implemented using a combination of fields that form a tuple or a dictionary. For instance, let’s consider a record representing a book in a library database, where the ISBN number can serve as the key:
book = {
"title": "Introduction to Database Systems",
"author": "C. J. Date",
"publication_year": 2004,
"isbn": "978-0321197849"
}
Here, the "isbn" field serves as the key, which uniquely identifies this particular book record.
Python Examples
In Python, data can be organized using data structures such as dictionaries, lists, and classes. Here are some examples of organizing data using Python:
- Dictionary example:
employee = { 'name': 'John Doe', 'age': 30, 'job_title': 'Software Engineer', 'department': 'IT', 'salary': 50000 } - List of dictionaries example:
employees = [ {'name': 'John Doe', 'age': 30, 'job_title': 'Software Engineer', 'salary': 50000}, {'name': 'Jane Smith', 'age': 25, 'job_title': 'Data Analyst', 'salary': 45000}, {'name': 'Mike Johnson', 'age': 35, 'job_title': 'Project Manager', 'salary': 60000} ] - Class example:
class Employee: def __init__(self, name, age, job_title, salary): self.name = name self.age = age self.job_title = job_title self.salary = salary employee = Employee('John Doe', 30, 'Software Engineer', 50000)
Storing Sparse Data: Compressed Sparse Row (CSR)
So far our records have been dense: every field of every record holds a value. But much real data is sparse — almost entirely empty. Think of a table of which customers bought which products (most customers buy almost none of the products), a word-document frequency matrix in a search engine, or the friendship graph of a social network (most pairs of people are not friends). Storing every empty cell explicitly wastes almost all of the space.
Compressed Sparse Row (CSR) storage solves this by keeping only the nonzero values, together with just enough bookkeeping to know where each one belongs. It is how scientific libraries (like scipy.sparse), search engines, and graph databases physically lay out sparse tables and adjacency matrices.
The Three Arrays
CSR replaces a matrix with three flat arrays:
| Array | One entry per… | Meaning |
|---|---|---|
data |
nonzero value | the values themselves, read left-to-right, top row first |
indices |
nonzero value | the column where the matching data entry lives |
indptr |
row, plus one extra | indptr[i] says where row i starts inside data/indices |
The name says it all: the rows are compressed — instead of storing each row’s empty cells, we store one pointer per row into the packed value list.
Encoding, Step by Step
Take this 3×3 matrix (the same one as in the model above and in the embedded example):
| col 0 | col 1 | col 2 | |
|---|---|---|---|
| row 0 | 1 | 0 | 2 |
| row 1 | 0 | 3 | 4 |
| row 2 | 5 | 6 | 7 |
- Walk the matrix row by row, skipping zeros, appending each nonzero value to
dataand its column toindices:- Row 0 contributes value
1(column 0) and value2(column 2). - Row 1 contributes
3(column 1) and4(column 2). - Row 2 contributes
5(column 0),6(column 1), and7(column 2). - Result:
data = [1, 2, 3, 4, 5, 6, 7],indices = [0, 2, 1, 2, 0, 1, 2].
- Row 0 contributes value
- Record where each row began. Row 0 started at position 0; row 1 started at position 2 (row 0 used two slots); row 2 started at position 4; and everything ends at position 7. So
indptr = [0, 2, 4, 7]— always one entry longer than the number of rows, so every row has both a start and an end.
Decoding, Step by Step
To read row i, slice between consecutive row pointers — this is the entire trick:
start = indptr[i]andend = indptr[i+1].- Row
i’s values aredata[start:end]. - Their columns are
indices[start:end]. - Every other column in row
iis zero.
Worked for row 1: start = indptr[1] = 2, end = indptr[2] = 4; the values data[2:4] = [3, 4] belong in columns indices[2:4] = [1, 2]. Filling the remaining column (0) with zero reconstructs row 1 exactly: [0, 3, 4]. As a bonus, end - start (here 4 - 2 = 2) is the number of nonzeros in the row — no scanning required.
A single element lookup, say cell (1, 2), is the same slice plus a search: among indices[2:4] = [1, 2], column 2 appears at offset 1 of the slice, so the value is data[2 + 1] = 4.
import numpy as np
from scipy.sparse import csr_matrix
m = csr_matrix((np.array([1, 2, 3, 4, 5, 6, 7]), # data
np.array([0, 2, 1, 2, 0, 1, 2]), # indices
np.array([0, 2, 4, 7])), # indptr
shape=(3, 3))
print(m.toarray())
Expected output:
[[1 0 2]
[0 3 4]
[5 6 7]]
Why Databases Care
- Space: a matrix with a million rows and columns but ~10 nonzeros per row needs about 107 stored numbers in CSR instead of 1012 cells dense — a 100,000× saving. (Our tiny 3×3 example is worse in CSR — compression only pays when most cells are empty.)
- Row access is fast: fetching a row is one slice — exactly the access pattern of “give me this customer’s purchases” or “give me this node’s neighbors.” The embedded example above exploits this to run depth-first search over a graph stored in CSR form.
- Trade-off: column access and single-cell updates are awkward (inserting a nonzero shifts everything after it, like inserting into the middle of an array). A sibling format, CSC (Compressed Sparse Column), makes the opposite trade — another instance of the recurring database theme that the right physical organization depends on your query pattern.
